TENDA O1 Wireless 2.4GHz 8dBi Outdoor CPE 500m Point to Point neTEo1

tweet_button TENDA O1 Wireless 2.4GHz 8dBi Outdoor CPE - GameDude Computers
TENDA O1 Wireless 2.4GHz 8dBi Outdoor CPE 500m Point to Point
b_201804171429479582b_201804171429478400b_201804171429488216b_201804171429503654
Dimension 190.35*80*67.5mm
Deployment Pole Mount
Application Scenarios Long range video surveillance,data transmission and WISP CPE
Frequency Range 2.4GHz
Wireless Link Rate 300Mbps
Antenna Antennas Gain:8dbi
Antenna Beamwidth:Horizontal: 60° Vertical: 30°
Button 1*Reset Button
Max. Power Consumption 2.6W
Waterproof Level IP65
LED PoE/LAN,WiFi,LED1,LED2,LED3
Power Method DC or Passive PoE
Passive POE Power Supply Passive power over Ethernet via PoE/LAN (+4,5pins -7,8pins) up to 30 meters
Input Voltage 9-12V DC
Reception Sensitivity MCS0: -92dbm
MCS7: -72dbm
Operating Mode AP/Station/WISP
Standard & Protocol IEEE 802.11b/g/n
Enable / Disable Wireless Radio Support
SSID Hidden Support
Wireless Client Isolation Support
SSID Isolation Support
Client Limitation For SSID Support
Wireless Access Control Support
Weak Signal Client Limitation Support
Transmit Power Adjustable Power by 1dBm
WMM Capable Support
ASPD Capable Support
Wireless Security 64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transparent Bridge Support
VLAN Tagging for SSID Support
DHCP Server Support
VPN Pass-through PPTP,L2TP
Remote Web Access Support
Schedule Reboot Support
Page Timeout Support
Ping Watchdog Support
Dyndns noip, dyndns.org
Network Diagnoses Ping, Traceroute, Signal Scan
Time & Date Setting Support
Firmware Upgrade Support
Backup / Restore Configuration Support
Username Management Support
Syslog Support
Managed by Controller PC Software -- CPE Assitant
Package Contents 1*Outdoor Point to Point CPE
1*Power Adapter
1*PoE Injector
2*Plastic Staps
1*Quick Installation Guide
Temperature Operating Temperature:-30℃ ~ 55℃
Storage Temperature:-40℃ ~ 70℃
Humidity Operating Humidity: 10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Defualt Settings Default login IP:192.168.2.1
Default Login Username:admin
Default Login Password:admin
Certification FCC/CE/RoHS
