￭ Support standard TFX form factor
￭ 500W continuous power output at 50°C operating temperature rated for 24/7 operation
￭ High efficiency with 80 PLUS Gold certification
￭ Silent running 80mm fan with 18 dBA minimum
￭ Multiple protection circuitry
￭ Single PCI-E 6+2pin connectors support
SPECIFICATIONS
| Product No. |
SST-TX500-G
|
| Max. DC Output |
500W
|
| Power density |
517W per liter
|
| Load Range |
|
Output
|
+3.3V |
+5V |
+12V |
+5VSB |
-12V |
|
Max.(Amps)
|
18A |
18A |
41.6A |
2.5A |
0.3A |
|
Peak (Amps)
|
/ |
/ |
/ |
/ |
/ |
|
Min.(Amps)
|
0A |
0A |
0A |
0A |
0A |
|
Range (%)
|
±5% |
±5% |
±5% |
±5% |
±10% |
|
Line Reg.(%)
|
±1% |
±1% |
±1% |
±1% |
±1% |
|
Ripple(mVp-p)
|
50mV |
50mV |
120mV |
50mV |
120mV |
|
| Model (safety certification) |
SST-TX500-G
|
| Color |
black (lead-free paint)
|
| Combined +3.3V & +5V |
100W
|
| Combined +12V |
499.2W
|
| Input Voltage |
90 ~ 264 Vrms
|
| Input Frequency Range |
47Hz ~ 63Hz
|
| PFC |
Active PFC (PF>0.9 at full load)
|
| Efficiency |
87% ~ 90% (at 20% ~ 100% loading)
|
| MTBF |
100,000 hours
|
| Operating temperature |
0 ~ 50°C
|
| Protection |
Over current protection
Over power protection
Over voltage protection
Short circuit protection
Under voltage protection
Over temperature protection
|
| Connectors |
1 x 24 / 20-Pin motherboard connector (350mm)
1 x 8 / 4-Pin EPS / ATX 12V connector (450mm)
2 x 8 / 6-Pin PCIE connector (350mm / 150mm)
4 x SATA connector ("350mm / 150mm" x 2)
2 x 4-Pin Peripheral connector (350mm / 150mm)
2 x 4-Pin Peripheral and 1 x 4-Pin Floppy adapter connector (350mm / 150mm / 150mm)
|
| Cooling System |
Single 80mm silent HYB fan
|
| Form factor |
TFX
|
| Noise Level |
18 dBA minimum
|
| Dimension |
85mm (W) x 65mm (H) x 175mm (D)
3.35" (W) x 2.56" (H) x 6.89" (D)
|
| Weight |
1.38 kg
|
| Certification |
80 PLUS Gold
|
| Other |
GPU Support list
Compatible with ATX12V v2.4
|
| ● Specifications presented on this page contains most recent revisions and may differ from those printed on retail boxes or manuals. |
